Duration

What Is Duration?

Duration is a measure of the sensitivity of the price of a bond or other debt instrument to a change in interest rates. A bond's duration is easily confused with its term or time to maturity because certain types of duration measurements are also calculated in years.

However, a bond's term is a linear measure of the years until repayment of principal is due; it does not change with the interest rate environment. Duration, on the other hand, is non-linear and accelerates as the time to maturity lessens.

How Duration Works

Duration can measure how long it takes, in years, for an investor to be repaid the bond’s price by the bond’s total cash flows. Duration can also measure the sensitivity of a bond's or fixed income portfolio's price to changes in interest rates.

In general, the higher the duration, the more a bond's price will drop as interest rates rise (and the greater the interest rate risk). For example, if rates were to rise 1%, a bond or bond fund with a five-year average duration would likely lose approximately 5% of its value.

Certain factors can affect a bond’s duration, including:

Types of Duration

The duration of a bond in practice can refer to two different things. The Macaulay duration is the weighted average time until all the bond's cash flows are paid. By accounting for the present value of future bond payments, the Macaulay duration helps an investor evaluate and compare bonds independent of their term or time to maturity.

The second type of duration is called modified duration. Unlike Macaulay's duration, modified duration is not measured in years. Modified duration measures the expected change in a bond's price to a 1% change in interest rates.

In order to understand modified duration, keep in mind that bond prices are said to have an inverse relationship with interest rates. Therefore, rising interest rates indicate that bond prices are likely to fall, while declining interest rates indicate that bond prices are likely to rise.

Macaulay Duration

Macaulay duration finds the present value of a bond's future coupon payments and maturity value. Fortunately for investors, this measure is a standard data point in most bond searching and analysis software tools. Because Macaulay duration is a partial function of the time to maturity, the greater the duration, the greater the interest-rate risk or reward for bond prices.

Macaulay duration can be calculated manually as follows:

M a c D = ∑ f = 1 n C F f ( 1 + y k ) f × t f P V where: f = cash flow number C F = cash flow amount y = yield to maturity k = compounding periods per year t f = time in years until cash flow is received P V = present value of all cash flows \begin{aligned}&MacD=\sum^n_{f=1}\frac{CF_f}{\left(1+\frac{y}{k}\right)^f}\times\frac{t_f}{PV}\\&\textbf{where:}\\&f = \text{cash flow number}\\&CF = \text{cash flow amount}\\&y = \text{yield to maturity}\\&k = \text{compounding periods per year}\\&t_f = \text{time in years until cash flow is received}\\&PV = \text{present value of all cash flows}\end{aligned} MacD=f=1∑n(1+ky)fCFf×PVtfwhere:f=cash flow numberCF=cash flow amounty=yield to maturityk=compounding periods per yeartf=time in years until cash flow is receivedPV=present value of all cash flows

The previous formula is divided into two sections. The first part is used to find the present value of all future bond cash flows. The second part finds the weighted average time until those cash flows are paid. When these sections are put together, they tell an investor the weighted average amount of time to receive the bond's cash flows.

Macaulay Duration Calculation Example

Imagine a three-year bond with a face value of $100 that pays a 10% coupon semi-annually ($5 every six months) and has a yield to maturity (YTM) of 6%. In order to find the Macaulay duration, the first step will be to use this information to find the present value of all the future cash flows as shown in the following table:

Image by Sabrina Jiang © Investopedia 2020

This part of the calculation is important to understand. However, it is not necessary if you already know the YTM for the bond and its current price. This is true because, by definition, the current price of a bond is the present value of all its cash flows.

To complete the calculation, an investor needs to take the present value of each cash flow, divide it by the total present value of all the bond's cash flows and then multiply the result by the time to maturity in years. This calculation is easier to understand in the following table.

Image by Sabrina Jiang © Investopedia 2020

The "Total" row of the table tells an investor that this three-year bond has a Macaulay duration of 2.684 years. Traders know that, the longer the duration is, the more sensitive the bond will be to changes in interest rates. If the YTM rises, the value of a bond with 20 years to maturity will fall further than the value of a bond with five years to maturity. How much the bond's price will change for each 1% the YTM rises or falls is called modified duration.

Modified Duration

The modified duration of a bond helps investors understand how much a bond's price will rise or fall if the YTM rises or falls by 1%. This is an important number if an investor is worried that interest rates will be changing in the short term. The modified duration of a bond with semi-annual coupon payments can be found with the following formula:

M o d D = Macaulay Duration 1 + ( Y T M 2 ) ModD=\frac{\text{Macaulay Duration}}{1+\left(\frac{YTM}{2}\right)} ModD=1+(2YTM)Macaulay Duration

Using the numbers from the previous example, you can use the modified duration formula to find how much the bond's value will change for a 1% shift in interest rates, as shown below:

$ 2.61 ⏟ M o d D = 2.684 1 + ( Y T M 2 ) \underbrace{\$2.61}_{ModD}=\frac{2.684}{1+\left(\frac{YTM}{2}\right)} ModD$2.61=1+(2YTM)2.684

In this case, if the YTM increases from 6% to 7% because interest rates are rising, the bond's value should fall by $2.61. Similarly, the bond's price should rise by $2.61 if the YTM falls from 6% to 5%. Unfortunately, as the YTM changes, the rate of change in the price will also increase or decrease. The acceleration of a bond's price change as interest rates rise and fall is called "convexity."

Usefulness of Duration

Investors need to be aware of two main risks that can affect a bond's investment value: credit risk (default) and interest rate risk (interest rate fluctuations). Duration is used to quantify the potential impact these factors will have on a bond's price because both factors will affect a bond's expected YTM.

For example, if a company begins to struggle and its credit quality declines, investors will require a greater reward or YTM to own the bonds. In order to raise the YTM of an existing bond, its price must fall. The same factors apply if interest rates are rising and competitive bonds are issued with a higher YTM.

The duration of a zero-coupon bond equals its time to maturity since it pays no coupon.

Duration Strategies

In the financial press, you may have heard investors and analysts discuss long-duration or short-duration strategies, which can be confusing. In a trading and investing context, the word "long" would be used to describe a position where the investor owns the underlying asset or an interest in the asset that will appreciate in value if the price rises. The term "short" is used to describe a position where an investor has borrowed an asset or has an interest in the asset (e.g. derivatives) that will rise in value when the price falls in value.

However, a long-duration strategy describes an investing approach where a bond investor focuses on bonds with a high duration value. In this situation, an investor is likely buying bonds with a long time before maturity and greater exposure to interest rate risks. A long-duration strategy works well when interest rates are falling, which usually happens during recessions.

A short-duration strategy is one where a fixed-income or bond investor is focused on buying bonds with a small duration. This usually means the investor is focused on bonds with a small amount of time to maturity. A strategy like this would be employed when investors think interest rates will rise or when they are very uncertain about interest rates and want to reduce their risk.

Why Is It Called Duration?

Duration measures a bond price's sensitivity to changes in interest rates — so why is it called duration? A bond with a longer time to maturity will have a price that is more sensitive to interest rates, and thus a larger duration than a short-term bond.

What Are Some Different Types of Duration?

A bond's duration can be interpreted in several ways. The Macauley duration is the weighted average time to receive all the bond's cash flows and is expressed in years. A bond's modified duration converts the Macauley duration into an estimate of how much the bond's price will rise or fall with a 1% change in the yield to maturity.

Dollar duration measures the dollar change in a bond's value to a change in the market interest rate, providing a straightforward dollar-amount computation given a 1% change in rates. Effective duration is a duration calculation for bonds that have embedded options.

What Else Does Duration Tell You?

As a bond's duration rises, its interest rate risk also rises because the impact of a change in the interest rate environment is larger than it would be for a bond with a smaller duration. Fixed-income traders will use duration, along with convexity, to manage the riskiness of their portfolio and to make adjustments to it.

Bond traders also use key rate duration to see how the value of their portfolio would change at a specific maturity point along the entirety of the yield curve. When keeping other maturities constant, the key rate duration is used to measure the sensitivity of price to a 1% change in yield for a specific maturity.
